Product Details:
|
| Material: | Aluminum | Size: | 164*75*180mm |
|---|---|---|---|
| Product Name: | Mikropul Venturi | Leadtime: | Negotiable |
| Treatment: | Polish And Shot Blasting | Usage: | Filter Cage Top And CPO |
| Lug: | Top 2 And Body 3 | Price: | Negotiable On Quantity |
| Highlight: | 180mm aluminum venturi,Mikropul aluminum venturi,Groove Cage Top Venturi |
||
Filter Cage Mikropul Aluminum Venturi 164x75x180mm Groove Cage Top Venturi
Mikropul Aluminum Venturi is used for Mikropul baghouse. It is a component for Mikropul baghouse. The venturis combinate to the dust filter cage/bag top and CPO.
| Item | 17AV001 |
| Name | Mikropul Venturi |
| Material | Aluminum |
| Size | 164*75*180mm |
There are two ways to install Mikropul Aluminum Venturi.
1) for top installation When filter bag and cage in position, insert Mikropul Aluminum venturi into bags and cages through CPO, and then twist to lock it on CPO. Clamp bag and cage to venturi.
2) for bottom installation Fasten and twist venturi to CPO, and pull packed bag and cage into venturi from the bottom. Clamp bag and cage to venturi.
Venturi Function:
a) support the cages and bags
b) if the spray torch (top blowing) is not straight venturi can adjust the compressed air flow, so reduce the scour to dust filter bags directly to extend the life of bags
c) make sure compress air reach deeper in bags to achieve a better dust cleaning
Packing
| Packaging Detail | Carton and pallet, or according to customer requirments |
| Delivery Detail | Normally within 30 days after receipt PO and deposit |
| Shipping terms | FOB Shanghai Port or CIF,CFR and more |
