Product Details:
|
| Name: | PTFE Dust Collect Filter Bag | Material: | PTFE Punch Felt |
|---|---|---|---|
| Finishing Treatment: | Water&Oil Repellent, PTFE Membrane, PTFE Impregnation | Bag Sizes: | Customized To Suit CPO And Filter Area |
| Bag Head: | Bead Cuff Or Seal Cuff | Bag Body: | Sewing Or Hot Sealing |
| Bag Bottom Layer: | Single Layer Or Double Layers | Bag Styles: | Round Bag, Oval Bag, Star/pleat Bag |
| High Light: | 700gsm high temperature filter bag,PTFE high temperature filter bag,ODM PTFE filter bag |
||
PTFE Filter Bags PTFE Dust Collect Bag Bag House PTFE Cage Filter Bag High Temperature Filter Bag
Specification
PTFE bag to the linear macromolecule structure thus has good heat resistance, abrasion resistance, and corrosion resistance, chemical stability, widely used in steel, power, waste incineration and other extreme flue gas filter conditions.
Datasheet
| Bag | PTFE Filter Bag | |||||
| Felt | PTFE Needled Felt | |||||
| Scrim | PTFE or P84 | |||||
| Weight | gsm | 700-750 | ||||
| Permeability | cfm | 20-30,PTFE lamination 3-7 | ||||
| Tensile Strength | Warp | >=N | 450 | |||
| Weft | >=N | 450 | ||||
| Break Elongation | Warp | < % | 25 | |||
| Weft | < % | 40 | ||||
| Working Temperature | Continuous | Dry | ℃ | 260 | ||
| Moist | ℃ | 260 | ||||
| Short term | ℃ | 290 | ||||
| Dry Shrinkage | Warp | <% | 1.5 | |||
| Weft | <% | 1.5 | ||||
| Specific Density | 2.3 | |||||
| Support Combustion | no | |||||
| Resistance | Hydrolysis | excellent | ||||
| Biological (mildew, bacteria) | no effect | |||||
| Alkalis | excellent | |||||
| Mineral Acids | excellent | |||||
| Orgnic Acids | excellent | |||||
| Oxidising Agents | excellent | |||||
| Orgnic Solvents | excellent | |||||
| Finishing | singeing, calendaring, PTFE lamination etc | |||||
Application
Cement factory, Iron & Steel factory, Power Plant factory, Waste Incineration factory, Glass plant etc
