Product Details:
|
| Item: | 17SPPSN550F | Material: | PPS Fiber |
|---|---|---|---|
| Thickness: | 1.8 ± 0.2 Mm | Air Permeability: | 12 ± 3 M3/m2/min@200Pa |
| Width: | Customized | Finishing: | Heat Setting、 Singing、Plain Finish、PTFE Immersion |
| Weight: | 550 G/m² | Pack: | Roll With Poly Bag |
| High Light: | Waterproof needle punched fabric,PPS Impregnation needle punched fabric,1.8mm needle punch material |
||
650g PPS And PTFE Blending Needled Felt With Lamination High Temperature Punched Filter Bag Cloths
Description
PPS fiber can keep intensity completely and bear chemistry naturing inherently, keep good filtration performance among the abominable environment, reach ideal service life. In coal boiler, rubbish incinerator, power plant of fly ash filtering of pulse clear dust catcher, PPS filter felts are an ideal filtration material. PPS filter felt is one of the main filter material able to bear the high temperature according to processed of production technology and artificial material of other high-temperature filter felt.
Main information of needled felt PPSPTN550F
| Item | 17SPPSN550F | |
| Name | 550g PPS punched felt with impregnation | |
| Construction | Needle-punched | |
| Fibre Composition | 100%PPS fiber | |
| Scrim Composition | 100%PPS | |
| Felt Area Weight | 550 ± 25 | g/m2 |
| Thickness | 1.8 ± 0.2 | mm |
| Air Permeability | 12 ± 3 | m3/m2/min@200Pa |
| Breaking Strength-warp | ≥900 | N / 5cm |
| Breaking Strength-weft | ≥1200 | N / 5cm |
| Breaking Elongation( N/5cm)-warp | ≤30 | % |
| Breaking Elongation( N/5cm)-weft | ≤45 | % |
| Dry Shrinkage warp(190℃) | ＜1.5 | % |
| Dry Shrinkage weft(190℃) | ＜1 | % |
| Operating Temperatures | ||
| Maximum Continuous | 160 | deg C |
| Maximum Surge | 190 | deg C |
| Finish | Heat setting, Singing,Plain Finish,PTFE Immersion | |
Chemical Resitance Properties
| Hydrolysis | Biological (mildew, bacteria) | Alkalis | Mineral Acids | Orgnic Acids | Oxidising Agents | Orgnic Solvents |
| poor | no effect | excellent | excellent | excellent | fair | excellent |
Production Flow
Needled felt, called punched filter cloths too, is a kind of nonwoven fabric, which is used for industry dust filtration. Needled punched felt is made of fiber and scrim, three layers construction with scrim inside. The first step is fiber feeding, and carding, needling, heat treatment, singeing, calendering, impregnation(oil and water proof), lamination (memberance) , inspection and pack , and then ship out.
