Product Details:
|
| Color: | Golden | Tear Resistant: | Yes |
|---|---|---|---|
| Fireproof: | Yes | Size: | Customizable |
| Temperature: | 260 | Mildew Resistant: | Yes |
| Product Name: | Airslide | Abrasion Resistant: | Yes |
| High Light: | Fire Resistant Airslide Band Belt,Aramid Conveyer Canvas Belt,Aerating Plate Fabric Airslide Belt |
||
Aramid 1313 Conveyer belt is made of aramid yarn, woven by special loom, interwoven by warp and weft. Its technical performance and product quality have reached the international advanced level. Can produce thickness of 3-12mm, width of 100-2200mm, can also be made according to the use of other specifications.
Airlsides are top-notch airslide bands and airslide fabrics that are highly durable and reliable for use in various industries. It is made of polyester fabric, which is fireproof, chemically resistant and temperature resistant up to 140°C. The airslide fabric can be customized according to your needs, and is used in a wide range of applications, such as dust collection, powder filling and conveying. It is also widely used for bulk material handling, dust-free conveying, and energy saving requirements. The airslide fabric is lightweight and easy to install, and has excellent air permeability and dust separation characteristics, making it a perfect choice for dust control and material transport. With its superior performance, airslide fabrics are the ideal solution for your airslide needs.
The technical performance and product quality of the filament breathable plate produced by our company have reached the international advanced level, and has the following advantages:
1). Flat surface, clear fabric, stable size, no deformation;
2). Uniform air permeability, no delamination, no ash return;
3). High temperature resistance, wear resistance, corrosion resistance; It can reach 180℃ instantly, and about 150℃ under constant temperature;
4) The use of high quality heat resistant, corrosion resistant chemical synthetic fiber, long service life, easy installation, minimal maintenance.
| Item | PETF4 | PETF4.5 | PETF5 | PETF5.5 | PETF6 | FETF6.5 |
|
Weight Kg/m2(±5％) |
3.0 | 3.6 | 4.0 | 4.3 | 4.65 | 5.2 |
|
Thickness mm(－0.2) |
4 | 4.5 | 5 | 5.5 | 6 | 6.5 |
| Tensile Strength kg/10mm | ＞450 | ＞500 | ＞550 | ＞600 | ＞700 | ＞800 |
|
Elongation Breaking % |
＜6 | ＜6 | ＜6 | ＜6 | ＜6 | ＜6 |
|
Permeability 10-3m3/m2.S(±20%) |
87.5 | 80 | 75 | 65 | 57.5 | 50 |
|
Permeability m3/m2.min(±20%) |
5.25 | 4.8 | 4.5 | 4 | 3.5 | 3 |
|
Temperature ℃ |
≤150 | ≤150 | ≤150 | ≤150 | ≤150 | ≤150 |
|
Peak Temperature ℃ |
180 | 180 | 180 | 180 | 180 | 180 |
Airslide, the brand name of the conveyer belt, is made in China and is highly durable and abrasion resistant. It can withstand temperatures of up to 140, making it suitable for a wide range of applications and scenes. The belt is also customizable in size, making it versatile and suitable for many different uses.
Usage: The product is mainly used as a supporting product of air chute and storage hopper, used for conveying dry powder materials. Widely used in high temperature cement, thermal power plant, alumina, bauxite, soda ash, gypsum, flour and other industries of horizontal transport and silo boiling.
Arislide provides technical support and services to ensure that our customers get the most out of their experience with our products. Our support team is available to answer any questions you may have and ensure that your purchase is as smooth as possible.
Airlslide is shipped in a box that is 19.7 x 19.7 x 7.9 inches in size.
It is then protected with bubble wrap and placed in a corrugated box for shipment.
The product is then shipped with a reputable carrier. Depending on the destination, Airslide may be shipped with UPS, FedEx, or a local courier.
The tracking details are provided to the customer after the product is shipped.
```
